RAM® C Size Double Socket Arm with 1.5" Round Ball Plate

RAM® C Size Double Socket Arm with 1.5" Round Ball Plate

The RAM-103U consists of the 1.5" diameter ball and socket system with one open socket end. This mount is designed to be used with any of the RAM mounting bases or cradles with a 1.5" diameter rubber ball. The RAM-202U round base has a 1.5" diameter rubber ball connected at right angles to a 2.5" diameter base. The plate has pre-drilled holes in the base, including the universal AMPS hole pattern.

KEY FEATURES

2.5" round plate connects to RAM® device holders containing the universal AMPS hole pattern
Includes C size medium length double socket arm; ball and socket technology allows for near-infinite adjustability
Made of powder-coated, marine-grade aluminum for durability and reliability in the most demanding environments

SPECIFICATIONS

LENGTH	118mm / 4.66" socket-to-socket
HOLE PATTERN	4-Hole AMPS: 1.181" x 1.496" 3-Hole 120-Degree: 1.812" Diameter
PLATE SIZE	2.5" Diameter
BALL SIZE	C Size (1.5")
WEIGHT CAPACITY	Standard Use: 1.81kg / 4 lbs Heavy-Duty Use: 1.36kg / 3 lbs
MATERIALS	Marine-grade aluminum
WEIGHT	423g
