Garmin GMU 22 Magnetometer Installation Kit
Product Description
Garmin GMU 22 Installation Kit

Use this installation kit to mount the GMU 22 magnetometer unit that is included in the High Performance G3X LRU Kit.

The GMU 22 magnetometer is a remote mounted device that provides magnetometer data to Garmin ADAHRS devices (GSU 25C/D). The Garmin ADAHRS and magnetometer replace traditional rotating mass instruments.

Table 1 - Contents of GMU 22 Connector Kit
Item Garmin P/N Quantity
Installation Rack, GMU 22 115-00481-10 1
Screw, 6-32x .250, Pan Head Phillips, Brass, w/Nylon 211-60037-08 3
Circular Connector, Female, 9 Ckt 330-00360-00 4
Circular non-Magnetic Backshell 330-90005-01 4
Socket Contact Mil Crp, Size 20 336-00022-00 10

Specifications
SKU 011-00871-10
Brand Garmin
Shipping Weight 0.5000kg
Unit Of Measure ea
